Outdoor Microphone

SPRW21 is a semi permanent microphone developed specif- ically for outdoor noise measurement. It does not have a built-in calibration device, so it needs to be calibrated peri- odically with a sound calibrator, which is suitable for short-term outdoor noise measurement.

SPRW21 meets IP55 protection grade, 60mm diameter windscreen and internal rain cover can fully protect the microphone to withstand harsh weather conditions such as wind, rain and snow, and prevent damage to the micro- phone by sand and dust. A single column bird spike can pre- vent birds from inhabiting and affecting the measurement accuracy.

PRW21 is a permanent microphone developed specifically for outdoor noise measurement, compared to semi perma- nent outdoor microphone, permanent outdoor microphone can be remotely inspected using electrostatic exciters. The built-in signal source can be controlled through serial com- munication to generate a specific sound pressure level exci- tation signal with a frequency of 1 kHz.



Features
Features

·Meet IP55 protection level and provide sufficient protection against wind, rain, snow, and dust

·Prevent bird habitation;

·The protective kit can be quickly disassembled, making it convenient for periodical sound calibration;

·IEPE constant current source power supply;

·Come with 1/4 inch bottom thread and can be installed on a tripod;

·Special acoustic design can minimize the impact of protective structures on free field frequency response;

Performance parameter
Performance parameter
Type
Semi Permanent Outdoor Microphone
Model
SPRW21
Internal Micro
1/2“Prepolarized Microphone
Sound Field
Free Field
Sensitivity
5mV/Pa
Frequency Range
10~20kHz
Dynamic Range
17dB(A)-136dB
Max Output Voltage
8Vrms
Power Supply
IEPE
Work Environment
Temp:-30℃ ~ +70 ℃; Humidity:0% ~ 98% RH
Interface
BNC
IP Grade
IP55
Size
Φ28×276mm
Electrostatic Actuator
-
Performance parameter
Performance parameter
Type
Permanent Outdoor Microphone
Mode
PRW21
Internal Micro
1/2“ Prepolarized Microphone
Sound Field
Free Field
Sensitivity
5mV/Pa
Frequency Range
10~20kHz
Dynamic Range
17dB(A)-136dB
Max Output Voltage
8Vrms
Power Supply
IEPE
Work Environment
Temp:-30 ℃~+70 ℃; Humidity: 0% ~ 98% RH
Interface
BNC
IP Grade
IP55
Size
Φ21×203mm
Electrostatic Actuator
Build-in electrostatic actuator and signal source, can generate an excitation signal with specific SPL 1kHz
